Installing SFP GBIC Transceivers
Issue 2 July 2005 49
2. For all other ports, connect an Ethernet copper cable (not supplied) directly to the ports. The
copper ports can operate with 2 pair (4 wire) or 4 pair (8 wire) CAT 5 Ethernet cables
(crossed or straight). The maximum cable length is 100 m (328 ft.).
3. Connect the other end of the cable to the Ethernet port of the PC, server, router,
workstation, switch, hub, or other end device.
4. Check that the appropriate link (LNK) LED lights up.
Installing SFP GBIC Transceivers
The SFP GBIC (Gigabit Interface Converter) have been tested for use with the C360 Gigabit
Ethernet ports. For a list of approved SFP GBIC transceivers, see: http://support.avaya.com
SFP GBIC transceivers are hot-swappable.
Safety Information
!
CAUTION:
CAUTION: You must operate the SFP GBIC transceivers under recommended operating
conditions, as specified for each transceiver.
!
WARNING:
WARNING: The use of optical instruments with this product will increase eye hazard.
!
ADVERTENCIA:
ADVERTENCIA: El uso de instrumentos ópticos en este producto aumentará el riesgo de peligro
para la vista.
Usage Restriction
When a SFP GBIC transceiver is inserted in the module but is not in use, protect the Tx and Rx
ports with an optical connector or a dust plug.
!
CAUTION:
CAUTION: Use only approved SFP GBIC transceivers. All approved SFP GBIC transceivers:
1) are 3.3V. Do not insert a 5VSFP GBIC.
2) use Serial Identification. Do not use a GBIC that utilizes Parallel
Identification.
