Avaya C360 - Policy Configuration Example

Avaya C360 Layer 3 Features
192 Installation and Configuration Guide Avaya C360 Multilayer Stackable Switches, version 4.5
Policy Configuration Example
Figure 29: C360 Policy
Display the DSCP to CoS map
of a policy-list
show ip access-list-dscp
Display summary information
regarding all configured access
lists
show ip-access-list-summary
Set the policy control source to
either local or remote policy
server
set qos policy source
Copy current policy and router
configuration to the startup
configuration file
copy running-config
startup-config
In order to... Use the following command...
2 of 2
Figure notes:
1. Voice packet
2. Data packet
3. Unauthorized packet
4. Policy Rules
5. Access Control
6. QoS
7. Packet dropped
8. Four egress queues (Highest, High, Normal, Low)
1
2
3
4
5 6
7
8
