Stacking (optional)
Issue 2 July 2005 45
Stacking (optional)
There are two main steps for creating stacks:
1. Installing the X360STK Stacking Module
2. Inter-Connecting Switches
Installing the X360STK Stacking Module
!
CAUTION:
CAUTION: C360 switches and stacking modules contain components sensitive to
electrostatic discharge. Touching the circuit boards unless instructed to do so
may damage them.
!
PRECAUCIÓN:
PRECAUCION: El switch C360 y sus módulos de ampliación contienen componentes sensibles a
descargas electrostáticas. Tocar las tarjetas sin autorización del personal técnico
puede dañarlas.
!
CAUTION:
CAUTION: Do not leave the stacking slots open. Cover empty slots using the blanking plates
supplied.
!
PRECAUCIÓN:
PRECAUCION: No deje las aberturas de ampliación abiertas. Cubrir las aberturas vacias con las
placas bloqueadoras proporcionadas con el equipo.
To install the stacking module in the C360:
1. Remove the existing stacking module or blanking plate from the back of the C360 switch.
2. Insert the stacking module gently into the slot, ensuring that the PCB (printed circuit board)
is aligned with the guide rails.
3. Press the module in firmly until it is completely inserted into the Avaya C360.
Note:
Note: Ensure that the screws on the module are properly aligned with the holes in the
chassis before tightening them.
4. Tighten the two screws on the side panel of the stacking module by turning the knurled
knobs clockwise.
