Avaya C360 - Appendix B: Configuring C360 QoS for Avaya IP Telephones; Configuration for ports connected to Avaya IP Telephones

Issue 2 July 2005 231
Appendix B: Configuring C360 QoS for Avaya IP
Telephones
Introduction
This appendix covers configuring C360 QoS settings for Avaya IP Telephony environments.
Tip:
Tip: For additional information, refer to the IP Telephony Deployment Guide on the
Avaya Support Site: http://support.avaya.com
.
Table 41: Configuration for ports connected to Avaya IP Telephones
Parameter Value CLI command
PVID Data VLAN set port vlan <vlan_num>
<module>/<port>
Port tagging None (i.e., not a trunk port) set trunk <module/port> off
Assigned port VLANs Data VLAN, VoIP VLAN set port static-vlan
<vlan_num> <module>/
<port>
Scheduling scheme Strict priority set queuing scheme strict
Trust policy in routing
mode
Trust DSCP+CoS for VoIP
LAN
Untrusted for Data VLAN
ip access-list-dscp trust
<policy-list-number>
trust-dscp
