Avaya C360 Front and Rear Panels
36 Installation and Configuration Guide Avaya C360 Multilayer Stackable Switches, version 4.5
*C360-PWR only
Tip:
Tip: All LEDs light during a reset.
PoE* Power over
Ethernet.
OFF - PoE disabled for this port
ON - PoE is enabled and power is being supplied
to an end-station
Blinking:
● PoE enabled, but no powered device is
detected, or
● Power supply error, or
● Not enough power
Table 4: C360 Right and Left Select buttons
On order to... Press...
Select the function
LED (see Table 3
)
Left or Right button
Reset the switch Both Right and Left buttons together for approximately
one second. All LEDs on the switch remain lit until the
procedure is complete.
Reset the stack Both Right and Left buttons together for five seconds. All
LEDs on the stack remain lit until the procedure is
complete.
Table 3: C360 Function LED Descriptions 3 of 3
LED
Name
Description LED Status
3 of 3
