Video Inputs
1 X SDI / HD-SDI per Video input
Loop 2 X SDI / HD-SDI per input - clean Monitoring
2 X SDI / HD-SDI per input with OSD
Video Outputs
2 X SDI / HD-SDI per Video output - clean
Monitoring 2 X SDI / HD-SDI per output
Audio Specifications
This section describes the audio specifications.
Control and Synchronization Specifications
This section describes the control and synchronization specifications.
- DNxHD SQ Includes the following compression rates:
• 145 Mbps
• 120 Mbps
• 290 Mbps
- DNxHD HQX Includes the following compression rates:
• 220 Mbps
• 185 Mbps
• 440 Mbps
Audio Specifications
Parameter Specification
Channels Up to 8 Uncompressed stereo audio tracks per video input channel.
Sampling 48 KHz, 16 or 24 bit precision
Embedded Audio PCM
Control and Synchronization Specifications
Parameter Specification
External Control • VDCP
• AirSpeed 5000API
