Connection Specifications
This section describes the connection specifications.
Connector Pinouts and Connections
The following connectors are listed in this section:
• “E
thernet Connector Specifications” on page 89
• “VDCP Commands Supported by OVS” on page 90
• “LTC Timecode Connector Speci
fications” on page 94
• “USB 2 Connec
tor Specifications” on page 94
w
In order to ensure emission compliance, all cables attached to connectors on the FastServe |
Live Edit or FastServe | Ingest chassis must be fully shielded and properly grounded to the
connector shell where possible.
Connection Specifications
Parameter Specification
Serial two (2) DB-9 RS-422 connectors
LTC IN one (1) XLR connector
SATA two (2) SATA connectors
Reference IN/Loop Two (2) BNC connectors (1 In and 1 Loop Out)
Keyboard/Mouse Ports Four (4) USB 2.0 connectors, for USB compatible keyboard and mouse.
VGA 15 pin connector. To attach a Maintenance Monitor.
Ethernet Ports 10GB (2) DAC (Direct Attach Cooper) SFP+ or Fiber SFP+
(on FastServe | Live Edit or FastServe | Ingest eth2 and eth3).
Ethernet Ports 1GB (2) RJ-45 connector, 10BASE-T, 100BASE-T, or 1000BASE-T, auto sensing
(on FastServe | Live Edit or FastServe | Ingest eth0 and eth1).
