Technical Specifications
The below table presents the current hardware specification of the FastServe | Live Edit Controller.
CPU Atom N270
Operating System Linux
Memory 1 GB RAM
System hard drive 8 GB SSD
LCD 5.7-inch (144.8 mm) 640x480 TFT color touchscreen
Controls 37 illuminated push buttons, 3 million operations minimum; user-
configurable jog wheel; T-bar controller
Channel configurations 8-channel server
7 in / 1 out
6 in / 2 out (PVW-PGM / 2PGM / MultiPGM)
4 in / 4 out
(Adding a second controller enables two more outputs to be configured)
Super slow motion configurations Supports 2x, 3x, 4x, and 6x normal speed cameras, combined with
single phase camera recording channels
Data interfaces 1 x Serial
2 x USB
2 x 1Gb Ethernet
1 x VGA
Input devices Support for external USB keyboard and USB mouse
Dimensions (H x W x D) 7.1 x 11 x 11.2 inches (180 x 280 x 285 mm)
Weight 10.6 lbs (4.8 kg) approximate
Power consumption 100–240V, 47–63 Hz, 60w (max)
Environmental conditions Operating temperature: 41°–104°F (5°–40°C)
Storage temperature: -40°–158°F (-40°–70°C)
Humidity: 90% max
