4. Connect the HD BNC cable.
Mounting the Imager onto a Surface
For a straightforward mounting installation, you can mount the right angle imager directly to a wall or other
mounting surface.
Note: The right angle imager can be mounted in place with either the mounting screws or the
mounting adhesive strip. Both options will be described below.
Use one of the following two options to install the right angle imager to the mounting surface.
Mounting the Imager onto a Surface 38
