Adapter System User Guide.
Note: The camera will reserve the 10.11.22.32/28 subnet for internal use while the USB Wi-Fi Adapter
is plugged in.
Assigning an IP Address
The device automatically obtains an IP address when it is connected to a network.
Note: If the device cannot obtain an IP address from a DHCP server, it will use Zero Configuration
Networking (Zeroconf) to choose an IP address. When set using Zeroconf, the IP address is in the
169.254.0.0/16 subnet.
The IP address settings can be changed using one of the following methods:
l
Device's web browser interface: http://<camera IP address>/.
l
Network Video Management software application (for example, the Avigilon Control Center™
software).
l
ARP/Ping method. For more information, see Setting the IP Address Using the ARP/Ping Method on
page55.
Accessing the Live VideoStream
Live video stream can be viewed using one of the following methods:
l
Web browser interface: http://< camera IP address>/.
l
Network Video Management software application (for example, the Avigilon Control Center™
software).
(Optional) Configuring Onboard Storage
To use the modular camera’s onboard storage feature, you must insert 1 microSD card into a microSD card
slot. While there are two microSD slots, currently the camera only supports a single microSD card in either
slot for onboard storage. For the location of the microSD card slots, see Main Unit on page8.
It is recommended that the microSD card have a capacity of 64 GB or more. Video Speed Class microSD card
required, with Class V10 or better recommended. If the microSD card does not meet the recommended
capacity or write speed, the performance of the onboard storage may suffer and result in the loss of frames or
footage.
Ensure the microSD card is designed for continuous video recording or the microSD card life expectancy may
Assigning an IP Address 50
