Tip: If it suits your installation, you can install the optional flat bracket onto the right angle
imager after mounting it to the wall as shown in the image above. Gently push the bracket
onto the imager until the bracket mounting clips click into place.
Installing with the Adhesive Strip
1. Peel the protective layer off of each side of the adhesive strip and discard.
2. Place the adhesive strip onto the mounting surface, making sure to align it with the placement you
want the imager to have. Align the right angle imager with the adhesive strip and press the imager
firmly onto the adhesive for at least 5 seconds.
Installing with the Adhesive Strip 40
