Azbil C35 Series User Manual

5-100
Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION

MS indicating lamp
The lighting conditions for the Multi Status (MS) display located at the center of the
console and three groups of the lighting statuses can be set with the priority put.
Item (Bank) Display Contents Initial value User level
MS indicating lamp ON
condition (1st priority)
(Setup bank)
0: Normally open (Normally OFF=0)
1: Normally close (Normally ON=1)
2 to 9: Internal event 1 to 8
10 to 13: Undefined.
14: MV1 (ON/OFF, Time proportional 1,
Heat-side, OPEN-side output)
15: MV2 (Time proportional 2, Cool-side,
CLOSE-side output)
16 to 17: Undefined.
18 to 21: DI1 to DI4
22 to 25: Undefined.
26 to 30: Internal contact 1 to 5
31 to 33: Undefined.
34 to 37: Communication DI1 to DI4
38: MANUAL
39: READY
40: RSP
41: AT
42: During ramp
43: Undefined.
44: Alarm
45: PV alarm
46: Undefined.
47: [mode] key pressing status
48: Event output 1 terminal status
49: Control output 1 terminal status
39 High function
MS indicating lamp ON
status (1st priority)
(Setup bank)
0: Lit.
1: Slow flashing
2: Flashing twice
3: Fast flashing
4: Left to right
5: Right to left
6: Reciprocating between left and right
7: Deviation OK
8: Deviation graph
9: MV graph
10:
Heat-side MV graph (For heat/cool control)
11: Cool-side MV graph (For heat/cool control)
12: MFB graph (including MFB being
estimated)
13: DI monitor
14: Internal contact monitor
15: Internal event monitor
1 High function
MS indicating lamp ON
condition (2nd priority)
(Setup bank)
Same as MS indicating lamp ON condition
(1st priority).
44 High function
MS indicating lamp ON
status (2nd priority)
(Setup bank)
Same as MS indicating lamp ON status
(1st priority).
6
MS indicating lamp ON
condition (3rd priority)
(Setup bank)
Same as MS indicating lamp ON condition
(1st priority).
1 High function
MS indicating lamp ON
status (3rd priority)
(Setup bank)
Same as MS indicating lamp ON status
(1st priority).
9
MS indicating lamp
deviation range
(Setup bank)
0 to 9999U 5U High function
