Azbil C35 Series

6-9
Chapter 6. LIST OF DISPLAYS AND SETTING DATA
Display Item Contents
Initial
value
User
level
Notes
Proportional band
(PID 6)
Same as PID 1 5.0 0 Same as PID 1
Integration time
(PID 6)
120 0
Derivative time (PID 6) 30 0
Manual reset (PID 6) 50.0 0
MV low limit (PID 6) 0.0 1
MV high limit (PID 6) 100.0 1
Cool-side proportional
band
(PID 6)
5.0 0
Cool-side integration
time (PID 6)
120 0
Cool-side derivative
time (PID 6)
30 0
Cool-side MV low
limit (PID 6)
0.0 1
Cool-side MV high
limit (PID 6)
100.0 1
Proportional band
(PID 7)
Same as PID 1 5.0 0 Same as PID 1
Integration time
(PID 7)
120 0
Derivative time (PID 7) 30 0
Manual reset (PID 7) 50.0 0
MV low limit (PID 7) 0.0 1
MV high limit (PID 7) 100.0 1
Cool-side proportional
band
(PID 7)
5.0 0
Cool-side integration
time (PID 7)
120 0
Cool-side derivative
time (PID 7)
30 0
Cool-side MV low
limit (PID 7)
0.0 1
Cool-side MV high
limit (PID 7)
100.0 1
Proportional band
(PID 8)
Same as PID 1 5.0 0 Same as PID 1
Integration time
(PID 8)
120 0
Derivative time (PID 8) 30 0
Manual reset (PID 8) 50.0 0
MV low limit (PID 8) 0.0 1
MV high limit (PID 8) 100.0 1
Cool-side proportional
band
(PID 8)
5.0 0
Cool-side integration
time (PID 8)
120 0
Cool-side derivative
time (PID 8)
30 0
Cool-side MV low
limit (PID 8)
0.0 1
Cool-side MV high
limit (PID 8)
100.0 1
