Chapter 6. LIST OF DISPLAYS AND SETTING DATA

Event configuration bank
Bank selection:
Display Item Contents
Initial
value
User
level
Notes
Internal Event 1
Configuration 1
Operation type
0: No event
1: PV high limit
2: PV low limit
3: PV high/low limit
4: Deviation high limit
5: Deviation low limit
6: Deviation high/low limit
7: Deviation high limit
(Final SP reference)
8: Deviation low limit
(Final SP reference)
9: Deviation high/low limit
(Final SP reference)
10: SP high limit
11: SP low limit
12: SP high/low limit
13: MV high limit
14: MV low limit
15: MV high/low limit
16: CT1 heater burnout/over-current
17: CT1 heater short-circuit
18: CT2 heater burnout/over-current
19: CT2 heater short-circuit
20: Loop diagnosis 1
21: Loop diagnosis 2
22: Loop diagnosis 3
23: Alarm (status)
24: READY (status)
25: MANUAL (status)
26: RSP (status)
27: During AT execution (status)
28: During SP ramp (status)
29: Control direct action (status)
30: ST setting standby (status)
(Invalid in this unit.)
31: During estimate of motor
opening (status)
32: Timer (status)
33: High and low limits of MFB value
0 0
Internal Event 1
Configuration 2
Digits are assigned from right to left
in the order 1, 2, 3, 4.
0000 0
1st digit: Direct/
Reverse
0: Direct
1: Reverse
2nd digit: Standby 0: None
1: Standby
2: Standby + Standby at SP change
3rd digit: EVENT state
at READY
0: Continue
1: Forced OFF
4th digit: Undefined 0
Handling Precautions
• If ROM version 1 of the instrument information bank (
I

d02
) is prior to
2.04, “33” cannot be set as [Internal Event configuration 1 operation type].
