159
www.balluff.com
3
Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
GS1 DataBar™
Expanded Set
Length 1
This feature specifies one of the barcode lengths for GS1 DataBar™ Expanded Length Control.
Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed
Length Mode. Length includes the barcode’s data characters only. The length can be set from 1
to 74 characters.
Table GS1 DataBar™ Expanded Length 1 Setting Examples provides some examples for setting
Length 1. See page 249 for detailed instructions on setting this feature.
GS1 DataBar™
Expanded
Length 1 Setting
Examples
STEP ACTION EXAMPLES
1 Desired Setting
01
Character
07
Characters
52
Characters
74
Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT GS1 DataBar™ EXPANDED LENGTH 1SETTING
4
Scan Two Characters
From Appendix D:
Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘5’ and ‘2’ ‘7’ AND ‘4’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select GS1 DataBar™ Expanded Set Length
1 Setting
Make a mistake? Scan the CANCEL barcode
to abort and not save the entry string. You
can then start again at the beginning.
CANCEL
$CXBL1
~
DEFAULT
01 = Length 1 is 1 Character
