Balluff BVS HS-P Series User Manual

164
3
Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Code 93 Set
Length 1
Specifies one of the barcode lengths for Code 93 Length Control. Length 1 is the minimum label
length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes
the barcode’s data characters only. The length can be set from 01 to 50 characters.
Table Code 93 Length 1 Setting Examples provides some examples for setting Length 1. See
page 249 for detailed instructions on setting this feature.
Code 93 Length
1 Setting
Examples
STEP ACTION EXAMPLES
1 Desired Setting
01
Characters
07
Characters
15
Characters
50
Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 93 LENGTH 1 SETTING
4
Scan Two Characters
From
Appendix D:
Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select Code 93 Set Length 1 Setting
Make a mistake? Scan the CANCEL barcode
to abort and not save the entry string. You
can then start again at the beginning.
CANCEL
$CC9L1
~
DEFAULT
01 = Length 1 is 1 Character
