References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Label ID
Examples
STEP ACTION EXAMPLES
1.
Scan the ENTER/EXIT
barcode
(Reader enters Programming Mode)
2.
Determine placement
of the Label ID
characters BEFORE or
AFTER with regard to
readed data using
Label ID
Control, starting on
page 63
Enable as
Prefix
Enable as
Suffix
Enable as
Prefix
Enable as Suffix
3.
Scan the barcode
selecting the
symbology type you
wish to designate
label ID characters for
using
Label ID
Symbology Selection −
1D
Symbologies, starting
on page 63.
DataBar
Omnidirec-
tional
Code 39
Interleaved 2
of 5
Code 32
4.
Custom Label ID
example (desired
characters):
D B * = C 3 + P H
5.
Find hex equivalents
from the ASCII
Chart(inside back
cover), then scan in
these digits/
characters using the
barcodes in the
section:
Appendix D:
Keypad, starting on
page 301. If you make
a mistake before the
last character, scan
the CANCEL barcode
to abort and not save
the entry string. You
can then start again at
the beginning.
44 42 2A 3D 43 33 2B 50 48
6.
Scan the ENTER/EXIT
barcode
(Reader exits Label ID entry)
7.
Scan the ENTER/EXIT
barcode once again
(Reader exits Programming Mode)
Result:
DB*[bar
code data]
[bar code
data]=C3
+[bar code
data]
[bar code
data]PH
