Balluff BVS HS-P Series User Manual

269
www.balluff.com
4
References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
4.7 Motion Features
4.7.1 Motionless
Timeout
This setting specifies the amount of time that the reader takes to assume that it is in a motionless
condition. The range for this setting is from 500 msec to 25.5 seconds, in 100 millisecond incre
-
ments.
Follow these instructions to set this feature.
1 Determine the desired setting.
2 Pad the result with leading zeroes to yield three digits. For example: 0.5 = 0005 = 00, 5 = 050,
20 = 200, etc.
3 Go to page 205 and scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Pro-
gramming Mode.
4 Scan the barcode: SELECT MOTIONLESS TIMEOUT SETTING.
5 Scan the appropriate three digits from the keypad in Appendix D: Keypad representing the
duration which was determined in the steps above. You will hear a two-beep indication after
the last character.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.
This completes the procedure. See Table Motionless Timeout Setting Examples for examples of
how to set this feature.
1F
EAN138
4A
ABC_CODABAR
20
ISBN_ID
4B
I2OF5_CIP
21
TWO_LABEL_PAIR
4C
C2OF5
22
I2OF5
4D
IND2OF5
23
CODABAR
4E
AZTEC
24
CODE39
4F
UPC-E_COMP
25
PHARMAC39
50
UPC-A_COMP
26
MSI_PLESSEY
51
EAN8_COMP
27
CODE93
52
EAN13_COMP
28
RSS_EXP_ID
53
EAN128_COMP
29
RSS_14_ID
54
DATA MATRIX_PROGRAMMING_LA-
BEL
2A
GTIN
55
LABEL_ID_MAX
2B
GTIN2
FF
INVALID_LABEL_TYPE
Hex
Value
Symbology ID Hex
Value
Symbology ID
NOTE
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
