Appendix A: Technical Specifications
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Performance Characteristics
Light Source LED
Roll (Tilt) Tolerance ± 180°
Pitch Tolerance ± 40°
Skew (Yaw) Tolerance ± 40°
Print Contrast
Minimum
15% minimum reflectance
Resolution
1D 2.5 mil
2D 4 mil
Depth of Field (Typical)
a
Symbology High Performance (HP)
Code 39
2.5 mils: 2-6 cm
20 mils: 3-70 cm
40 mils: 3-110 cm
EAN 13 13 mils: 3-60 cm
PDF-417 10 mils: 2-30 cm
DataMatrix
4mil: 2-6 cm
10mil: 2-20 cm
Minimum
Element Width
High Density:
1D Minimum Resolution = 2.5 mil
PDF-417 Minimum Resolution = 4 mil
Data Matrix Minimum Resolution = 5 mil
a
13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, 300 lux ambient light, 20°C, label inclination 10°
