2. CSE-200 Specifications
2.2 CSE-2 00 specifications
Base Unit
Dimensions (HxWxD) 205mm x 115mm x 45m m (excl. antennas) / 8.1” x 4.5” x 1.8”
205mm x 150mm x 135m m (incl. antennas) / 8.1" x 5.9" x 5.3"
Po we r con s umption
Operation: 6W (typical) / 18W (max)
Standby: 2.6W (ECO standby) / 0.4W (Deep standby)
Weight
600g / 1.32lbs
Anti-theft system
Kensington lock
Humidity
Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-conden sing
Temperature range
Operating: 0°C to +40°C (+32°F to +104°F)
Max: 3 5°C (95°F) at 3000m
Storage: -20°C to +60°C ( -4°F to +140°F )
Connections
1x Ethernet LAN
2x (back) + 1x (front) USB
Audio analog line out on mini jack socket (3.5mm), digital S/PDIF
Frequency band
2.4 GHZ and 5 G Hz
Reach
Adjustable with signal strength modulation; m ax. 30m (100 ft) between ClickShare
Button and ClickShare Base Unit
Wireless transmission protocol IEEE 802.11 a/g/n
Authentication protoco l WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X in network integration mode
Extended d esktop Available (depending on the driver of your graphics card)
iPad, iPhone and Android
compatibility
Sharing of documents, browse r, cam era for both Android and iOS devices via ClickShare
app
Audio
Via HDMI, analog via Audio Jack 3.5mm, S/PDIF
Number of simultaneous
connections
16
Number of sources simultaneous
on screen
2
Noise Level Fan less
Output resolution 1920x1200
Frame rate Up to 30 fps
Video outputs 1x HD MI
Operating system Windows 7/8/8.1/10
Mac O S X 10.10/10.11
Android 4.1 and later (ClickShare app)
iOS 7.0 and later (ClickShare app)
Certifications FCC/CE
Warranty 3 years standard
Possible to extend to 5 years
Button
Weight 75 g/0.165 lb
Dimensions (HxWxD) 16.3 m m x 59.3 m m x 16 2.52 m m / 0.64” x 2.335” x 6.398”
6 R5900023 CSE-200 11/04/2016
