4. CSE-200 Installation
1. Right click on the sound icon in the system tray and selec t Playback devices.TheSound window opens.
2. Select Sp eakers C lickShare, select Set default and click Apply.
4.7 LAN connection
About LAN connection
The B ase Unit c an be c onnected to a local network or directly to a laptop. For normal oper ation, a LAN conne ction is not necessary.
The L AN con nection c an be used:
•toconfigure your C SE- 200 unit
• to update the software
• for ma intenance purposes
• for network integration of you r CSE-200 unit
How to connect
1. Insert a network c able with RJ-45 connector into the LAN port.
2. Connect the other side to a LAN .
4.8 Power connection
About power
This product is intended to be supplied by a UL Listed Power U nit marked “Class 2” or “LPS” or “Limited Power Sour ce” with output
rated 12 V DC 1.5A min or Power ov er Ethernet (PoE) Plus IEE E802.3at Type 2 compliant Power Sourcing Equipment (PSE) rated
42.5-57 V DC, 0.4-0.3A.
An external power adapter is delivered with the product.
Once the Base unit is powered, it starts up. Then the power button can be used to switch on or off.
How to connect the external power adapter.
1. Plug the barrel c onnector of the power adapter into the power input of the Base unit.
2. Slide a power input adaptor piece (US, CN, EU or UK) on th e power adapter of the ClickShare . Use the one which is applicable
in your country.
a) Slide down the button on the ada pter (1).
b) Insert the latch (2) of the adapter piece into notch (3)
1
2
3
Image 4-4
Mounting adapter piece
18 R5900023 CSE-200 11/04/2016
