10. Scheimpflug
If yes, the B ack Focal Length is correctly adjusted.
If no, repeat with step 4.
9. Is the projected image in the corners as sharp as in the middle?
If yes, proceed with the procedu re "Fixation of the Le ns Holder front plate", page 98.
If no, Sch eimpflug adjustment is required. See procedure "Scheimpflug adjus tment", page 96, prior to fixate the Lens Holder
front plate. CAUTION: Skip the action, in the Sc heimpflug adjustment procedure, to turn the three Scheimpflug adjustment nuts
until the front of the nut is equally aligned with the front of the threaded rod!
R5906847 DP2K SLP SERIES 02/06/2017
103
