B. Pin configurations
568A and 568B may be use d interchangeably in a s ystem SO LONG AS both ends of a given cable are terminated the same way.
568A + 568B wiring is a c rossover cable.
568A + 568A wiring is a straight cable.
568B + 568B wiring is a straight cable.
The mapping of the channels is done according to the E thernet wiring scheme a nd gives us 100 Ohm per pair.
R5906847 DP2K SLP SERIES 02/06/2017
157
