Index
HD-SDI settings 47
HDD 56, 79–80
Remove 79–80
Storage 56
HDMI 59
HDMI 1.4 69
Specifications 69
HDMI 2.0 59, 66
Specifications 66
High Brightness precautions 10
I
ICMP 53
ICMP HD D 72
Status LEDs 72
Troubleshooting 72
ICMP reset 77
ICMPintroduction 54
ICP board 4 6
IMB 50
Important s afety instructions 6
Importer 167
IMS 50
Initial inspection 20
Input 41–42
Introduction 42
Input & Communication 43
Local Keypad 43
Install 36, 86, 131, 139–142, 144
Covers 131
Left side cover 1 41
Lens 36
Light Source cover 144
Side cover plate 139
Top cover 142
Top cover plate 140
Touch Panel 86
Installation 23–24, 26–27
Installation 26
Adjustments 26
Overview 24
Process 23
Installation requirements 16
Projector weight 16
Intall 143
Rear cover 14 3
Integrated Cinema Processor 46
Integrated M edia Block 50
Integrated M edia Server 50
Internal clock 76
Introduction 42, 51
Cinema Controller 51
Communication 42
Input 42
K
KDM 74
Keypad 39, 44
Backlight 39, 44
Color 39, 44
L
LAN 57
Large dust filter 122
Replace 122
Left side cover 135, 141
Install 1 41
Remove 135
Lens 36–38, 94, 96, 128
Cleaning 128
Focus 38
Installation 36
Removal 37
Scheimpflug 94, 96
Shift 38
Zoom 38
Lens Holder 33, 98
Front plate 98
Lenses 33
lens selection 35
Lenses 33– 34
Available 34
Lens Holder 33
Light Processor 136, 138–140
Side cover plate 13 8–139
Top cover plate 136, 140
Light Processor compartment 111
Closing off 111
Light Source cover 132, 144
Install 144
Remove 132
Local Keypad 43
M
Maintenance 119
3 m onth 119
Maintenance procedures 121
Maintenance program 117–118
1 M onth 118
Mechanical check 20
N
Network Time Protocol 76
Notice on optical radiation 4
Optical radiation 4
Notice on safety 4
O
Obtain 78
Device cert ificate 78
Own e r’s record 5
P
Pedestal 149
Dimensions 149
Physical installation 28
Pin configuration 154
Comm unication ports 154
Pin configurations 151, 155
ICMP 155
Position 88
Touch Panel 88
Product safety labels 9
Production 166
Projector status 45
R
RAID broken 56
RAID recovery 56
Rear cover 133, 143
Install 143
Remove 133
Rear projection 12
Remove 37, 79–80, 131–136, 138
Covers 131
HDD 79–80
Left side cover 135
Lens 37
Light Source co ver 1 32
Rear cover 133
Side cover plate 138
170
R5906847 DP2K SLP SERIES 02/06/2017
