4. Physical installation
5
46
3
2
Image 4-6
4. Secure the AC power supply cord by f astening the cable gland (reference 3 im age 4-6). Us e a 24m
m open end wrench
5. Install the cover of the main AC compartment. Fasten the two captive thumb screws (reference 1 image 4-7).
1
Image 4-7
6. Install the rear cover of the projector. See procedure "Installation of the rear cover", page 143.
32
