R5906788-03 Thor series154
A.1 Specifications of the Thor
Specifications
Resolution 4,096 x 2,160
Display technology three chip 4K 6P RGB Laser DLP
Housing Sealed DMDs and optical assembly
Input resolution range up to 4K (4,096 x 2,160)
Light output Up to 15000 ANSI lumens
Contrast 1,100 : 1 ANSI Contrast (w/WHC Lens) / 6,000 :1 On/Off contrast
Light source 6P RGB Laser
Light source lifetime 30,000 hours or more, replaceable illumination
Lenses 1.13 - 1.72 : 1 4K-VHC LNS Only
1.35 - 1.86 : 1 4K-VHC LNS or DC4K HC
1.46 - 2.10 : 1 4K-VHC LNS or DC4K HC
1.65 - 2.60 : 1 4K-VHC LNS or DC4K HC
2.00 - 3.35 : 1 4K-VHC LNS or DC4K HC
Lens Shift adjustable: vertical and horizontal, depending on lenses
Inputs Barco Alchemy ICMP included in the projector:
2x HDMI2.0a (up to 4K 2D 60fps)
JPEG2000 2K & 4K DCI play-out
High Frame Rates 3D up to 120fps (60fps per eye)
2x 3G-SDI inputs
16x AES/EBU audio channels (2x RJ45)
3D Color3D (Barco Laser3D): Native 6-primary color-3D system. Only
requires color filter glasses (Dolby3D glasses cannot be reused)
Active glasses systems
Polarization recuperation systems
Control TCP/IP, 8 x GPIO, RS232
Dimensions Projector: 744 x 1,445 x 706 mm / 29.3 x 56.9 x 27.8 inches (with feet, no
lens)
Chiller with the following dimensions: 701 x 701 x 800 mm / 27.6 x 27.6 x
31.5 inches
Weight Projector: 200kg (~440lb),
Chiller: ~115kg (~250lb)
Power requirements • Projector: 200 - 240 / 346 - 415 V 50 - 60 Hz 16A 3W+N+PE (Y
connection)
• Power cord size range: 4 sq mm to 6 sq mm, 10AWG to 8AWG
• Circuit breaker range: 25A to 40A
• Chiller: 230 / 400V 3W+N+PE 16A 2.5 sq mm (Y connection) or 208V /
3W+PE (delta connection) Max. 16A per phase
Power consumption • Projector @ full laser power: 3.5 kW (2D or Polarization D) / 2.0 kW
(Barco Laser3D - 6P)
• Chiller @ full laser power: 2.0 kW (2D or Polarization 3D) / 1.6 kW
(Barco Laser3D - 6P)
BTU per hour 18,500 BT/U
