R5906788-03 Thor series158
A.4 Dimensions of the Thor series projector
Dimensions
293,5
1446
859
1135
415
293,5
298
741,6
675
1211
33,3
117,5
33,3
117,5
EXIT DRAIN
EXIT DRAIN
PONT OF GRAVITY
707,5
246,5
325675
112
Image A-1: Dimensions given in millimeters.
