R5906788-03 Thor series156
• Power cord size range: 4 sq mm to 6 sq mm, 10AWG to 8AWG
• Circuit breaker range: 25A to 40A 200-240V 3W+PE 28A 50-60Hz
(delta connection)
• Power cord size: 6 sq mm, 8AWG
• Circuit breaker: 40A
• Chillers: 230/400V 3W+N+PE 16A, 2.5 sq mm (Y connection) or 208V /
3W+PE (delta connection) / Max. 16A per phase
Power consumption • Projector @ full laser power: 6.7 kW (2D or Polarization 3D) / 3.6 kW
(Barco Laser3D -6P)
• Chillers @ full laser power: 3.0 kW (2D or Polarization 3D) / 2.5 kW
(Barco Laser3D -6P)
BTU per hour 32,150 BT/U
Noise level (typical at 25°C/
77°F)
Loud
Operating temperature 30°C (86°F) Max. (projector and chillers)
Operating humidity 75% Max. (projector and chillers)
DCI Desktop front
Warranty Limited 2 years parts and labor.
Certifications CE, ETL/UL/FCC
* Example
A.3 Specifications of the ICMP
Specifications
Integrated Cinema Media
Processor
DCI 4K 2D up to 60fps*
DCI 4K 3D (24 or 30 fps per eye)*
DCI High Frame Rates 2K 3D up to 120fps (60fps per eye)
JPEG 2000 bit-rates up to 625Mbps
Dual-channel color-correction
MPEG-2 (4:2:0 and 4:2:2 up to 60fps)
2x HDMI2.0a (up to 4K 2D 60fps)
2x 3G-SDI inputs
16x AES/EBU audio channels (2x RJ45)
8x GPI, 8x GPO (4x RJ45)
2x Gbe for content connectivity & ingest
2x front-accessible USB 3.0 for fast ingest
2x front-accessible USB 2.0
Video and audio watermarking: Civolution NexGuard
Closed captioning devices: Support for SMPTE 430-10
* 4K 24fps is standard. For 4K 60 fps / 4K 3D on ICMP upgrade modules a
license is required. Newly-built 4K Barco Alchemy projectors have the
license standard included.
Barco Web Commander Projector dashboard
Projector control board
Show player/editor/scheduler
Automation, 3D, Ingest
Smart projector status
Via HTML5 web browsers including iOS & Android tablets
