R5906788-03 Thor series 155
Noise level (typical at 25°C/
77°F)
TBD
Operating temperature 30°C (86°F) Max. (projector and chillers)
Operating humidity 75% Max. (projector and chillers)
DCI Desktop front
Warranty Limited 2 years parts and labor.
Certifications CE, ETL/UL/FCC
A.2 Specifications of the Thor+
Specifications
Resolution 4,096 x 2,160
Display technology three chip 4K 6P RGB Laser DLP
Housing Sealed DMDs and optical assembly
Input resolution range up to 4K (4,096 x 2,160)
Light output Up to 32,000 ANSI lumens
Contrast 1,100 : 1 ANSI Contrast (w/WHC Lens) / 6,000 :1 On/Off contrast
Light source 6P RGB Laser
Light source lifetime 30,000 hours or more, replaceable illumination
Lenses 1.13 - 1.72 : 1 4K-VHC LNS Only
1.35 - 1.86 : 1 4K-VHC LNS or DC4K HC
1.46 - 2.10 : 1 4K-VHC LNS or DC4K HC
1.65 - 2.60 : 1 4K-VHC LNS or DC4K HC
2.00 - 3.35 : 1 4K-VHC LNS or DC4K HC
Lens Shift adjustable: vertical and horizontal, depending on lenses
Inputs Barco Alchemy ICMP included in the projector:
2x HDMI2.0a (up to 4K 2D 60fps)
JPEG2000 2K & 4K DCI play-out
High Frame Rates 3D up to 120fps (60fps per eye)
2x 3G-SDI inputs
16x AES/EBU audio channels (2x RJ45)
3D Color3D (Barco Laser3D): Native 6-primary color-3D system. Only
requires color filter glasses (Dolby3D glasses cannot be reused)
Active glasses systems
Polarization recuperation systems
Control TCP/IP, 8 x GPIO, RS232
Dimensions Projector: 744 x 1,445 x 706 mm / 29.3 x 56.9 x 27.8 inches (with feet, no
lens)
Two chillers, each with the following dimensions: 701 x 701 x 800 mm /
27.6 x 27.6 x 31.5 inches
Weight Projector: 235kg (~520lb)
Chillers: ~115kg (~250lb) per chiller (two chillers needed)
Power requirements • Projector: 200-240/346-415V 50-60Hz 16A 3W+N+PE (Y connection)
Specifications
