Barco Thor series Installation Manual

25
About this chapter
This chapter briefly describes all different components of the complete projection system based on the Thor.
For more detailed information related to the projector we refer to other chapters in this document. For the other
components in the system we refer to its own documentation set of the component. Note that the latest
version of this document and all other related documentation sets are available on the Barco website.
Different components of the projection system.
1 2 3
5
4
6
7
8
9
Image 3-1
1 Chiller unit without expansion for DMD cooling
(not used for Thor).
2 Chiller unit equipped with expansion for DMD
cooling.
3 Chiller cooling circuit expansion for DMD cooling.
4 Hoses.
5 Projector (with or without external safety
interlocks).
6 Touch Panel (optional).
7 Communicator (PC).
8 Commander (ICMP).
9 Web Commander (ICMP).
Overview
•
Thor
• Chillers and hoses
• Safety system
• Communicator Touch Panel
• Communicator PC version
R5906788-03 Thor series
System overview 3
