ex
4 Product description
Subject to technical modifications
Revision A / 04/2019
29 / 106
4.4.2 External contacts
Non-approved accessories!
Loss of function and risk of explosion.
Only connect base stations and chargers that have been specified by BARTEC.
The approved accessories are shown in the system overview (see system overview, Chapter 15.2).
The model is clearly indicated on the type label.
Figure 10 External contact on Bluetooth hand-held scanner
4.4.3 Communication via Bluetooth
Three types of connection are available for communication of the hand-held scanner via Bluetooth:
Point-to-point mode
Hand-held scanner is connected to a base station, standard
mode
Multi-point-to-point mode
Up to 7 hand-held scanners are connected to one base
station. The connection between base station and hand-
held scanner can only be made with one device.
(No multi-point-to-point is possible with the universal supply
module. Only 1 hand-held scanner can therefore be
connected to the universal supply module).
HID mode
Direct communication with Bluetooth host without base
station. The Bluetooth hand-held scanner can communicate
with a Bluetooth-enabled device (e.g. smartphone) directly
without a base station.
Table 25 Communication via Bluetooth
