Bartec BCS 3600ex Series - Connecting to the HMI: Connecting the Hand-Held Scanner to the HMI

Handscanner
BCS 3600
ex
series
7 Connection /
commissioning (qualified
personnel)
Subject to technical modifications
Revision A / 04/2019
75 / 106
7.4 Connecting to the HMI: connecting the hand-held scanner to the HMI
The function is only guaranteed if the cables you connect for your configuration have been specified
by BARTEC (see system overview, Chapter 15.2, P. 104).

Pay attention to the HMI manual.
When connecting to an HMI or other device, it must be ensured that the Ex-technically relevant values
are not exceeded or undercut.

Chapter 3.5 Observe Ex-relevant values when connecting to UVM or other systems.
Furthermore, it must be noted that the functional values listed in chapter 3.5 are also observed.

Connect the connection cable of the hand-held scanner in the HMI to the terminals provided for
this purpose.
