Handscanner
BCS 3600
ex
series
4 Product description
Subject to technical modifications
Revision A / 04/2019
31 / 106
Pos.
Description
Function
7 Page button Connected hand-held scanners transmit a
beep when the page button has been
pressed
8 Retainer Holding the hand-held scanner in the
base station
9 Drill hole Mounting the base station to the wall
10
Hole
Water drainage
11
Connection
Connecting connection cable to base
station
12
Rubber feet
Prevent the base station slipping
13
Drill holes
Mounting the base station to the wall
14 Adjusting screw Adjusting retainer to wall mounting or for
use on the desk top
15 Cable routing Feeding the connection cable to the
connection
16 Connection Protecting the connection
17
Cover
Relieving the strain on the connection
cable
18
Drill holes
Mounting the base station to the wall
19
Rubber feet
Prevent the base station slipping
Table 26 Construction base station
