6 Configuration
Subject to technical modifications
Revision A / 04/2019
61 / 106
There are the following methods to realize pairing with Bluetooth enabled device.
Pairing – Programmable codes for different host types
Scanning the respective programmable code from the corresponding Zebra "Product Reference Guide"
for the DS36X8.
Chapter 4 - "Radio Communication" - "Host Types
- Keyboard Emulation
- Simple Serial Interface (SSI)
- Serial Port Profile (SPP)
Detailed explanations of the individual host types can be found in the Zebra manual.
Pairing – Keyboard Emulation
The most common method to connect the hand-held scanner to a Bluetooth enabled device is
described in detail below.
Prepare the hand-held scanner for pairing with other
Bluetooth enabled device.
Keyboard Emulation (HID)
"HID BT LE (Discoverable) scanning the barcode.
Enables the host PC to establish an HID (Human Interface
Device) connection to the hand-held scanner via Bluetooth
low-energy radio. The hand-held scanner can be recognized
on the host PC (slave mode).
How to establish a connection (initial setup only):
- Scan the barcode HID BT LE (Discoverable).
- In the Bluetooth Manager on your host PC, find
the hand-held scanner as a "DS36xx" device.
- - Select your hand-held scanner and establish the
HID BT LE (Discoverable)
Table 51 Connection of Bluetooth enabled devices using a pairing barcode
For more information and detailed descriptions, refer to the Zebra "Product Reference Guide" for
the DS36X8.
Chapter 4 - "Radio Communication
