Bartec BCS 3600ex Series - Page 85

Handscanner
BCS 3600
ex
series
7 Connection /
commissioning (qualified
personnel)
Subject to technical modifications
Revision A / 04/2019
83 / 106
3. Make settings in the terminal program and connect with Connect.
Example for BCS 3608
ex
Example for BCS 3678
ex
4. Read the barcode with the scanner and check the data in the terminal program.
5. Data transfer is OK if the barcode data is displayed in the "Received Data" window.
Otherwise check connection and programming.
