Specifications
A: R82GB0CA.PDM
B: R82DE0CA.PDM
E: 080403 / T. Wenger
G: 020403 / TCS
Section 3
Page 9
19/27 EMERGENCY STOP (HD)
The IMM control system is deactivated when the
contact is opened. The contact must be in
series with the IMM EMERGENCY STOP.
20/32 Handling device operation (HD)
Operating mode switch: Opened contact signals
to IMM: Operation with HD (Position 1).
Closed contact signals to IMM: Operation
without HD (Position 0).
21/32 Ejector retracted (from HD)
The closing contact returns the tool ejector.
22/32 Ejector forward (from HD)
The closing contact moves the tool ejector
forward.
23/32 Core pullers in removal position
(from HD)
Move core pullers into position to remove the
moulded component.
24/32 Core pullers retracted (from HD)
Move core pullers into position to move in the
HD.
