5 Assembly and
Operation
5.1 Modules
1 Pneumatic system (refer to 5.2)
2 Electric motors (refer to 5.3.1)
3 Terminal box 1 (refer to 5.3.3)
4 Terminal box 2 (refer to 5.3.4)
