Description:
Terminal bus fault in signal communication with
terminals
Description:
Non-supported terminal at ”n”.
KL1104 input terminals
Signal – LED 1
Signal – LED 3
A
B
C
D
E2
E3 E4
1
2
3
4
5
6
7
8
Power-
contacts
Top view
E1
R8B2_019.PDF
KL2134 output terminals
Signal – LED 2
Signal – LED 1
Signal – LED 3 Signal – LED 4
A
B
CD
A1
A2
A3 A4
1
2
3
4
5
6
7
8
Power-
contacts
+24 V
0 V
Top view
R8B2_020.PDF
Error code Error cause
5 pulse n
R8B2_GB158.XLS
Error code Error cause
7 pulse n
R8B2_GB159.XLS
