Section - 5
Page - 12
Assembly and Operation
?
DM435 Digital hybrid module – 8 x 24 V DC
outputs, 8 x 24 V DC inputs
Features:
8 digital inputs
24 V DC input voltage
1 ms input delay
8 digital outputs
24 V DC switching voltage
Max. continuous current: 0.5 A per output
Short circuit and overload proof
R8B2_031.JPG R8B2_032.JPG
DO722 Digital output module – 8 240 VAC /
24 V DC isolated relay outputs
Features:
8 isolated relay outputs, make contact elements
Switching voltage
240 VAC/24 V DC
2.5 A continuous current
