Mounting

Operation manual b maXX BM4100 (NWR)

Document no.: 5.04052.09

of 142

Figure 21: Mounting instruction BM4163-S

Device BM4163-S

A - screws 4 x M8

B - washers 4 x (8,4 x 17)

c - mounting space c = 0,7 mm
