Connections on the front side
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
188
of 328
7.15
Connection
m An
alog input/output
Power supply
analog and
digital
Analog
input
-10V to +10V
Analog
input
(0) ... 4 to 20 mA
Analog
output
-10 V to +10 V
reference potential BSA
Figure 87: Connection of analog inputs/outputs SVP
m Digital inputs/outputs
Power supply
analog and
digital
24V int
GND int
24V int
GND int
24V
24V
24V
24V
24V int
GND int
24V
24V
24V
24V
Figure 88: Connection of digital inputs/outputs SVP
