Baumuller b maXX 5000 Series - 11.1.6 EtherCAT, VARAN, POWERLINK cable

Accessories and spare parts
Instruction handbook b maXX 5000
Document No.: 5.09021.16
249
of 328
11
11.1.4 Control voltage supply/signal cable
Cross-section
1)
1.5 mm²
Maximum length (without digital I/O)
2)
User-defined
Maximum length with digital I/O 30 m
Connection to device Without/with wire end ferrule (clamp terminal)
1)
The type of routing is user-defined.
2)
The length of the cable has no influence on adherence to the EMC law.
11.1.5 Signal bus cable
Type Length Part number
Signal bus cable, 10-pin BM5X2X 50 mm 426781
Signal bus cable, 10-pin BM5X3X 75 mm 426782
Signal bus cable, 10-pin BM5X4X 100 mm 426783
Signal bus cable, 10-pin BM5X7X 220 mm 481585
Signal bus cable, 10-pin BM5X9X 470 mm 481586
(Max. permissible number of axis unit
s for the signal bus: 12)
11.1.6 EtherCAT
®
, VARAN, POWERLINK
®
cable
m Availab
le Ethernet connecting cables:
type: patch cable, STP
Type Length [m] Part number
K-ETH-33-0-0.5 0.5 325160
K-ETH-33-0-01 1 325161
K-ETH-33-0-02 2 325162
K-ETH-33-0-03 3 325163
K-ETH-33-0-04 4 325317
K-ETH-33-0-05 5 325164
K-ETH-33-0-10 10 325165
Additional lengths upon request
