Baumuller b maXX 5000 Series - Load Cycle According EN61800-6

Technical data
Instruction handbook b maXX 5000
Document No.: 5.09021.16
75
of 328
3
3.4.4 Load cycle according EN61800-6
Operation with constant load
Figure 31: Typical current-time diagram: operation with constant load
BM503X
BM5031 10 kW (100 % P
rated
)
BM5032 18 kW (100 % P
rated
)
BM51XX
I
b
BM5174 S (air-cooled)
BM5174 C (cold plate)
100 A (100 % I
rated
)
BM53XX
I
b
at 2 kHz I
b
at 4 kHz I
b
at 8 kHz I
b
at 16 kHz
BM5323 - 2 x 3 A (100 % I
N
) 2 x 2.1 A (70 % I
N
) -
BM5325 - 2 x 6 A (100 % I
N
) 2 x 4.2 A (70 % I
N
) -
BM5326 - 12 A (100 % I
N
) 8.4 A (70 % I
N
) 4.8 A (40 % I
N
)
BM5327 - 20 A (100 % I
N
) 14 A (70 % I
N
) 8 A (40 % I
N
)
BM5328 - 30 A (100 % I
N
) 21 A (70 % I
N
) 12 A (40 % I
N
)
BM5331 - 2 x 12 A (100 % I
N
) 2 x 8.4 A (70 % I
N
) 2 x 4.8 A A (40 % I
N
)
BM5332 - 2 x 20 A (100 % I
N
) 2 x 14 A (70 % I
N
) 2 x 8 A (40 % I
N
)
BM5333 - 2 x 30 A (100 % I
N
) 2 x 21 A (70 % I
N
) 2 x 12 A (40 % I
N
)
BM5334 - 40 A (100 % I
N
) 28 A (70 % I
N
) 16 A (40 % I
N
)
BM5335 - 60 A (100 % I
N
) 42 A (70 % I
N
) 24 A (40 % I
N
)
BM5372-S 120 A (100 % I
N
) 90 A (75 % I
N
) 63 A (52 % I
N
) 45 A (37 % I
N
)
BM5372-F
BM5373-S 150 A (100 % I
N
) 120 A (80 % I
N
) 84 A (56 % I
N
) 50 A (33 % I
N
)
BM5373-F 60 A (40 %
I
N
)
BM5374-S 180 A (100 % I
N
) 150 A (83 % I
N
) 105 A (58 % I
N
) 50 A (27 % I
N
)
BM5374-F 100 A (55 % I
N
) 75 A (41 % I
N
)
BM5375-F 180 A (100 % I
N
) 180 A (100 % I
N
) 130 A (70 % I
N
) 90 A (50 % I
N
)
BM5376-S 180 A (100 % I
N
) 150 A (83 % I
N
) 105 A (58 % I
N
) 50 A (27 % I
N
)
BM5376-F 180 A (100 % I
N
) 130 A (72 % I
N
) 90 A (50 % I
N
)
