Mounting of toroidal cores
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
120
of 328
6.4
6.4.2 Mounting the toroidal cores
Carry out mounting as follows:
1 Ke
ep suitable fastening components readily available.
2 Mount the toroidal
cores
3 La
y the mains cable through the toroidal cores, see ZInstallation procedure– as from
page 141.
Figure 51: Toroidal cores mounted
Bolts 6 x M8
Washers 6 x (8.4 x 25)
