Shielding plan side-by-side mounted system
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
134
of 328
7.9
7.9.2 Shielding connection with shield sheet
7.9.2.1 Mounting shield sheet
Refer to ZAccessories kit shielding– as from page 286.
Air-cooled/
water-cooled 
devices
Figure 57: Mounting shield sheet air-cooled devices
Cold plate 
devices
Figure 58: Mounting shield sheet cold plate devices
