Baumuller b maXX 5000 Series - 3.4.2 Electrical data of the BM53 XX

Electrical data
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
66
of 328
3.4
3.4.2 Electrical data of the BM53XX
m Double axis unit safety
BM532
3 BM5323-A BM5325 BM5325-A
Input rated power
1) 9)
3.5 kW 5.75 kW 7.0 kW 9.9 kW
DC link voltage (U
DC
)
1)
60 V - 760 V
DC link capacitance (internal) 235 µF
DC link discharge time 
(internal DC link capacitance)
250 s
Output voltage
(U
AC
)
1) 3)
0 - 500 V
Output frequency at 4 kHz
4)
0 - 450 Hz
Output rated current
(I
AC
RMS)
1) 2) 5)11)
at 
4 kHz
4)
2 x 3 A 2 x 4.5 A 2 x 6 A 2 x 8.5 A
Output rated current
(I
AC
RMS)
1) 2) 5)11)
at 
8 kHz
4)
2 x 2.1 A 2 x 3.15 A 2 x 4.2 A 2 x 5.9 A
Output rated current
(I
AC
RMS)
1) 2) 5)11)
at 
16 kHz
4)
-
Output peak current
(I
AC
RMS)
1) 5) 6)11)
at 
4 kHz
4)
2 x 9 A 2 x 18 A
Output peak current
(I
AC
RMS)
1) 5) 6)11)
at 
8 kHz
4)
2 x 6.3 A 2 x 12.6 A
Output peak current
(I
AC
RMS)
1) 5) 6)11)
at 
16 kHz
4)
-
Short-time operation KB 300 % 200 % 300 %
Max. length of time peak current
6)
Refer to ZLoad cycle accor
ding EN61800-6– as from page 75
Power loss with regard to power supply Max. 55 W Max. 82.5 W Max. 100 W Max. 141 W
Power loss with regard to
control voltage supply
(air-cooled)
7)
Max. 35 W
Power loss with regard to
control voltage supply
(cold plate cooling)
7)
Max. 35 W
Current of the integrated brake control
(option)
8)
Max. 2 x 2.0 A
Cooling air requirement power heat sink 15 m
3
/h - 15 m
3
/h -
Cooling air velocity power heat sink - > 5 m/s - > 5 m/s
Cooling air requirement internal space of device - 10 m
3
/h
with cold plate
-
Footnotes refer to Zpage 73–.
