Baumuller b maXX 5000 Series - 7-Segment Display Controller

Display and operating elements
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
96
of 328
4.4
4.4.3.1 7-segment display controller
Refer to parameter manual for detailed description of drive states and state transitions.
0: Low, 1: High
0
NOT READY TO SWITCH ON Drive message „Not ready for switching power on“
1
SWITCH-ON INHIBIT Inhibit voltage, e.g. quick stop active
2
READY TO SWITCH ON Drive shutdown
Control word: xxxx x110
Pulse enable = 0
Quick stop = 1 (low active)
3
SWITCHED ON Control word: xxxx x111
Pulse enable = 1
Quick stop = 1
4
OPERATION ENABLED Control word: xxxx 1111
Pulse enable = 1
Quick stop = 1
5
BETRIEB SPERREN AKTIV
6
OPERATION INHIBIT ACTIVE Pulse enable = 0
7
QUICK STOP ACTIVE Quick stop = 0 (low active)
E
ERROR RESPONSE ACTIVE
F
ERROR Error message
Reset via control word 0xxx xxxx
or reset stored errors 0
➝ 1
P
Parking axis
NOTE!
In addition the error No. is displayed, refer to ZBM5
1XX and BM53XX error detec-
tion– as
from page 237.
Display State 
drive man
ager
Meaning
