106 Alarms
Manual 41018v0800 SIGMA Spectrum Infusion System
Revision B Operator’s Manual
AIR STILL DETECTED The AIR STILL DETECTED screen displays if the Pump still detects air in the
loaded IV tubing when the door is closed after an AIR IN LINE alarm.
Reassess the IV line for air
■ Ensure all clamps are closed before opening the door and unloading the IV
set from the Pump.
1. Close the roller clamp to prevent free flow.
2. Open the door to evaluate the IV set.
3. Check the tubing in the tubing channel for the presence of air.
4. Unload the IV set to remove the air if necessary.
5. Follow facility policy and procedures to remove the air manually.
6. Reload the IV set.
7. Close the Pump door.
8. Confirm the IV line has been assessed.
9. Open the slide clamp and roller clamp.
10. Press RUN to resume the infusion.
OR
To continue the infusion:
1. Press confirm and continue the infusion with air detected.
2. Press RUN to continue the infusion.
If using multiple Pumps:
■ Confirm correct IV line when checking for the presence of air.
■ If IV line removal is required, confirm correct IV line before removing.
WARNING Priming.
Prior to connecting to patient, prime IV set
following the standard gravity priming
instructions included with the administration
set, remove all air, close roller clamp and
slide clamp, load IV set into the Pump,
close the door, open slide clamp and roller
clamp.
Alarms Action
