Compatible IV Sets 123
SIGMA Spectrum Infusion System Pump Operating Software Version 8.00
Operator’s Manual For Use With MDL Version 8.0
COMPATIBLE IV SETS
Compatible Baxter IV Sets
The following is a partial listing of the Baxter IV Sets compatible with the SIGMA Spectrum Infusion
Systems that have been calibrated for Baxter IV set tubing. For a full listing of compatible sets
refer to DOC 11182 on the Baxter website (www.sigmapumps.com) or call Baxter Technical
Support at 800.356.3454.
WARNING IV Set Usage.
Do not use an IV set for longer than the manufacturer’s labeled set
change interval to reduce risk of infection and to maintain flow rate
accuracy.
NOTE: In the IV Set List, noted superscripts reference specific warnings provided at the end of
the compatible set list. See “Compatible Baxter IV Sets – WARNINGS ” on page 127.
All sets must include a Blue Slide Clamp on the section of the set to be placed into the Pump. See
Figure 136.
Figure 136. Blue Slide Clamp.
No. Brief Description
Primary Set Macro (10 drops/mL)
1C8109s Solution Set, 101” (2.6 m), Male Luer Lock Adapter
1C8160s Solution Set,69” (1.8 m) Male Luer Lock Adapter
1C8296s Solution Set, 125" (3.2 m), Male Luer Lock Adapter
1C8727s CLEARLINK System, CONTINU-FLO Solution Set, 113" (2.9 m), 3 Luer Activated Valves,
Male Luer Lock Adapter with Retractable Collar
2
2C6255s CLEARLINK System, CONTINU-FLO Solution Set, 89" (2.3 m), 2 Luer Activated Valves,
Male Luer Lock Adapter, Large Bore 4-Way Stopcock Extension Set, 34" (86 cm), Vol. 5.4
mL, 2 Luer Activated Valves, Male Luer Lock Adapter
2, 8
2C6401s Interlink® System, Solution Set, Injection Site, Lever Lock Cannula, Luer Lock Adapter, 76"
(1.9 m)
2C6419s Interlink® System, Solution Set with DUO-VENT Spike, 92" (2.3 m), Injection Site, Male
Luer Lock Adapter
To Next Page
