Using the BayStack 350 10/100/1000 Series Switch
E-2
304376-B Rev 00
Aging Time 300 seconds MAC Address Table (page 3-18)
Find an Address 00-00-00-00-00-00
(no MAC address assigned)
Port Mirroring Address A: 00-00-00-00-00-00
(no MAC address assigned)
Port Mirroring Address B: 00-00-00-00-00-00
(no MAC address assigned)
Create VLAN 1 VLAN Configuration (page 3-22)
Delete VLAN blank field
VLAN Name VLAN # (
VLAN number
)
Port Membership U (all ports assigned as
untagged members of
VLAN 1)
Port 1 VLAN Port Configuration (page 3-24)
Filter Tagged Frames No
Filter Untagged Frames No
Filter Unregistered Frames No
Port Name Port # (
port number
)
PVID 1
Port Priority 0
Note:
The following two fields only appear when the port selected in the Port field is configured with an
optional gigabit MDA.
Primary VLAN Tagging Untagged
Secondary VLAN Tagging Tagged
Port 1 VLAN Display by Port (page 3-27)
PVID 1 (read only)
Port Name Port # 1 (read only)
Traffic Class Low Traffic Class Configuration (page 3-28)
Status Enabled (for all ports) Port Configuration (page 3-30)
Autonegotiation Enabled (for all ports
)
Speed/Duplex 100Mbs/Half (when
Autonegotiation is Disabled)
(continued)
Table E-1. Factory Default Settings for the BayStack 350 Switch (continued)
Field Default setting Appears in this CI screen
